    Details Specifications Resources Accessories
    Model W60P W56P W52P
    Compare
    Download Datasheet Datasheet Datasheet
    Features Standby Time 400h 400h 100h
    Talk Time 30h 30h 10h
    Battery Lithium Lithium NiMH
    Headset  3.5 mm 3.5 mm 2.5 mm
    Indoor Range/Outdoor Range 50m/300m 50m/300m 50m/300m
    Handset number of base Up to 8 handsets Up to 5 handsets Up to 5 handsets
    SIP Accounts 8 5 5
    Simultaneous Voice Calls 8 4 4
    Repeater
    DECT standard CAT-iq2.0 CAT-iq2.0 CAT-iq2.0
    3-way Conferencing
    Speed Dial
    Display LCD Display 2.4" 240 x 320  TFT colour display 2.4" 240 x 320  TFT colour display 1.8" 128 x 160 TFT colour display
    LCD Backlight
    Audio Wide-band Codecs Opus, AMR-WB (optional), G.722 G.722 G.722
    Narrow-band Codecs PCMU, PCMA, G.726, G.729, iLBC G.711(A/µ), G.723, G.726,G.729, iLBC G.711(A/µ), G.723, G.726,G.729, iLBC
    HD Voice
    Interface Ethernet Interface 10/100M 10/100M 10/100M
    POE
    Bluetooth x x x
    Wall Mountable Base

    For more complete product documentation, click Here

    DD10K RT20U RT20 (EU Version) Protective Case for Yealink W56H

    DD10K

    • Compatible with Yealink SIP- T41S/T42S with FW 66.82.0.35 or
    • later, SIP-T58A with FW V83 or later and SIP-T53/T53W/T54W/
    • T57W/VP59
    • Reliable Connection
    • Ease-of-use
    • Plug and Play
    • High Transmission Rate
    • Datasheet Download

    RT20U

    • Compatible with DECT GAP
    • Compatible with Yealink W52P/W56P/W60P IP DECT Phone
    • Plug & play setup
    • Auto association
    • Star connection (max 5)
    • Clear status LED display
    • Slim Design
    • Wall Mountable
    • Datasheet Download

    RT20 (EU Version)

    • Compatible with DECT GAP
    • Compatible with Yealink W52P/W56P IP DECT Phone
    • Plug & play setup
    • Auto association
    • Star connection (max 5)
    • Clear status LED display
    • Slim Design
    • Datasheet Download

    Protective Case for Yealink W56H

    • Shock proof
    • Crash proof
    • Scratch proof
    • Dirt proof
    • Available Model:W56H
    • Color: Black
    • Certification: REACH
